Material：
Housing：LCP
Contact：Phosphor Bronze C5210-sh.c2680
Shell：SUS304-3/4H
Electrical：
Current Rating：0.5MΩ Max
Contact Resistance:100MΩ Max
Insulation Resistance：100MΩ Min/500VDC
Dielectric Withstanding Voltage: 500VAC/minute
Operating Temperature：-25oCTo+85oC
Mating Cycles：7,000 Insertions
|
