Description:
10/100Base-TX surface mount RJ45 single 1X1 Tab-UP/DOWN with or without LEDs Integrated Magnetics connector, designed to support applications such as:set Tox and network cards (NIC)
Features and benefits
· RJ451X1,Tab-DOWN 8-Pin with internal magnetics
· Options:1X1 for 10/100 Base-TX
· Available with and without LEDs
· Suitable for CAT 5 and 6 Fast Ethemet cable or better UTP
· Internal magnetics are 100% electrically tested for Hi-POT and functionality
Electrical Performance Summary
· Internal magnetics options available
· Meets or exceeds IEEE 802.3ab standard for 100Base-TX
· 350 µH minimum OCL with 8 mA DC bias current
· Hugh Performance for maximum EMI suppression
· Minimum 1500 Vrms isolation per IEEE 802.3 requirement
Electrical Specifications @25oC-Operating Temperature 0oC to 70oC
|
